Type | 48cm / 19" wide color TFT active matrix LCD | |
Display Area | 410mm horizontal x 259mm vertical; 483mm diagonal (16,1" horizontal x 10,0" vertical; 19" diagonal) | |
Optimum Resolution | 1440x900 | |
Contrast Ratio | 1000:1 (typ); 10,000,000:1 (dynamic) | |
Viewing Angles | 170º horizontal, 160º vertical @ contrast ratio > 10:1 | |
Response Time | 5ms (typ) | |
Light Source | Long life, 30,000 hrs. (typ) | |
Brightness | 250 cd/m2 (typ) | |
Panel Surface | Anti-glare | |
VIDEO INPUT | ||
Analog | RGB analog (75 ohms, 0.7/1.0 Vp-p) | |
Digital | DVI-D (TMDS, 100 ohms) | |
Frequency | Fh: 24~82kHz, Fv: 50~75Hz | |
Sync | H/V separated (TTL), composite sync-on-green | |
COMPATIBILITY | ||
PC | VGA up to 1440x900 non-interlaced | |
Mac® | Power Mac™ G3/G4/G5 up to 1440x900 | |
CONNECTOR | ||
Analog | 15-pin mini D-sub (VGA) | |
Digital | DVI-D (TMDS, 100 ohms) | |
Power | 3-pin plug | |
AUDIO | ||
Speakers | 2x2-watt | |
POWER | ||
Voltage | AC 100–240V (universal), 50/60Hz (auto switch) | |
Consumption | 15W (typ) | |
CONTROLS | ||
Basic | Power, 1, down, up, 2 | |
OSD | Auto image adjust, brightness, contrast, input select (analog, digital), ViewMatch® color adjust (sRGB, 9300K, 7500K, 6500K, 5400K, default, user color - RGB), information (resolution, H/V frequency, pixel clock, model number, serial number), manual image adjust (H/V position, H size, fine tune, sharpness), setup menu (language, resolution notice, OSD position, OSD timeout, OSD background), memory recall | |
ERGONOMICS | ||
Down 5º, Up 20º | ||
OPERATING CONDITIONS | ||
Temperature | 31–104º F (0–40º C) | |
Humidity | 10–90% (non-condensing) | |
DIMENSIONS | ||
Physical With Stand | 17.7" x 17.0" x 8.2" (450mm x 434mm x 209mm) | |
Physical Without Stand | 17.7" x 13.4" x 2.6" (450mm x 341mm x 66mm) | |
Packaging | 21.5" x 20.3" x 6.4" (546.1mm x 515.6mm x 162.6mm) | |
WEIGHT | ||
Gross | 13.6 lb. (6.2 kg) | |
Net With Stand | 10.3 lb. (4.7 kg) | |
Net Without Stand | 8.1 lb. (4.0 kg) | |
VESA® MOUNT | ||
100mm x 100mm | ||
REGULATIONS | ||
UL, cUL, FCC-B, CB, CE, ENERGY STAR®, NOM, GS (covers GS), ERGO (ISO13406-2 &MPR II), MPR II, GOST-R + 20 original copies hygienic, SASO, PCBC, VCCI, BSMI, CCC, PSB, C-TICK, MIC (KCC), WEEE, RoHS | ||
POWER MANAGEMENT | ||
Meets MPR II and ENERGY STAR® standards | ||
PACKAGE CONTENTS | ||
LCD display, power cable, VGA video cable, DVI cable, audio cable, Quick Start Guide, ViewSonic Wizard CD (User Guide and drivers) | ||
WARRANTY | ||
Three-year limited warranty on parts, labor and backlight |
Autor | Komentarz |
hobbista
2010-04-14, 08:02
|
Ciekaw jestem czy będzie wart zakupu?
|
CAD, CAM, CAE, PDM
2010-04-14, 08:24
|
W tej cenie, przyznam ze jest przyzwoity.
|
